车间粉尘处理的好方法，车间粉尘由吸尘罩通过风管经风机的引力下进入脉冲布袋除尘器，在挡风板的作用下，气流向上流动，流降低，部分大颗粒粉尘由于惯性作用被分离出来落灰灰斗，细微的含尘气体进入中箱体滤袋的过滤净化，粉尘被阻留在滤袋的外表面，净化后的气体经滤袋口进入上体箱后高空排放，粉尘由经布袋除尘器的排灰阀排出。

A good method for dust treatment in the workshop. The dust in the workshop enters the pulse bag filter through the suction hood and the suction of the fan through the air duct. Under the action of the wind deflector, the airflow flows upwards and decreases. Some large particles of dust are separated from the ash hopper due to inertia, and fine dust containing gases enter the filtering and purification of the middle box filter bag. The dust is trapped on the outer surface of the filter bag, and the purified gas enters the upper box through the filter bag mouth and is discharged at high altitude. The dust is discharged through the ash discharge valve of the bag filter.

结合厂房面积及加工设备的实际需要风量，设计管路及分支管道，按设备扬尘的大小，来设计管道分支的直径，粉尘从管道中由负压风机带动脉冲袋式除尘设备从，从设备的下风口进入除尘设备灰仓，通过除尘仓的喷吹和吸附，来完成正常气流的清洁流通，干净气体从上风口进入烟筒排除，有沉降室的，粉尘会排入沉降室，没有沉降室的会用布袋收集起来，由专人清理。

Based on the actual air volume required by the factory area and processing equipment, design pipelines and branch pipelines, and design the diameter of pipeline branches according to the size of equipment dust. Dust is collected from the pipeline by negative pressure fans with arterial flushing bag dust removal equipment, and from the lower air outlet of the equipment, it enters the dust removal equipment ash bin. Through the spraying and adsorption of the dust removal bin, the normal air flow is cleaned and discharged. Clean gas enters the chimney from the upper air outlet, and if there is a settling chamber, the dust will be discharged into the settling chamber. If there is no settling chamber, it will be collected with cloth bags and cleaned by a dedicated person.
